PRODUCT Details

A sand cleaning machine, beach cleaner, or (colloquially) sandboni is a vehicle that drags a raking or sifting device over beach sand to remove rubbish and other foreign matter. Beach cleaning machines work by collecting sand by way of a scoop or drag mechanism and then raking or sifting anything large enough to be considered foreign matter, including sticks, stones, litter and other items. Similar applications include lake beaches,sandfields for beach volleyball and kindergaten and playing field sandpits.
Beach cleaner can work quickly on the beach with a tractor generally powered for 50-90-hoesepower. The spline-mounted pump enables the beach cleaner to sift all kinds of waste and offshore floater. And the waste is collected into the collecting tank controlled by hydraulic drive and then can be tipped directly onto a truck. Finally ,the machine can aerate and compress the sand.

Beach cleaner can be used all kinds of dry or wet beach, also can remove waste like litter, other debris from the beach (Cigarette butts, glass shards, pieces of wood, beverage cans, pebbles and so on ), unwanted seaweed and other polluted things.

Technology Data

Model Ld-1000

Capacity screen surface

+2.2 M²

Operating cleaning width

1000mm

Cleaning depth

0-110mm

Beating rotating axles

1

Overall length

4285mm

Width

2140mm

Height

1450mm

Size of tires (standard)

26x12.00-12

Net weight

1240kg

Unloading height

1200mm

Hopper capacity

1M³

Power take-off speed

720RPM / PTO Z6,1 3/8"

Transmission

Hydraulic

Noise

75dB

Min-max power

35-60 kw

Drawbar eye

Cat.1

Tension roller for the screening belt

No

Tractor hydraulics

2 double-acting circuits

Sifting band screen

15x25/20x30/25x35mm

Sifting band metal

17/21 mm

Max. cleaning capacity

9000 m2


Working sketches of cleaning
